Axle Scale/Wheel Weigher
RoughDeck® AX Axle Scale
RoughDeck® AX-1 Axle Scale
RoughDeck® AX Axle Scale
- (W x L x H): 32 x 84 x 6 in
- Axle capacity - tandem platforms - 60,000 lb (two scales 30,000 lb each)
- Includes (2) 3/4-10 NC eye bolts
- Contains four environmentally sealed, IP67 20,000 lb single-ended shear beam load cells per platform
- Treaded top plate with side access junction box
- JB4SS TuffSeal® signal trim junction box
- Top access foot adjustment holes
- Carbon steel captured ball feet
- 20 ft SURVIVOR® EL147HE cable
- Non-Legal for Trade
AX3040 Axle Scale
RoughDeck® AX-1 Axle Scale
RoughDeck® AX Axle Scale
- System includes two platforms with anchor brackets and four on/off ramps with anchor tabs
- Sizes: 7, 12 and 14 ft lengths
- Construction: Steel or aluminum
- Axle capacity - tandem platforms - 60,000 or 80,000 lb (30,000 lb or 40,000 lb each)
- Includes (4) 5/8-11 NC eye bolts
- JB4SS TuffSeal® signal trim junction box
- Treaded top plate with lifting eyes
- 10 ft EL146HE Interconnect cable
- 50 ft EL147HE cable to connect weigh pad to indicator
- Non-Legal for Trade
RoughDeck® AX-1 Axle Scale
RoughDeck® AX-1 Axle Scale
Load Ranger Wheel Pad Scale
- 50,000 lb capacity
- Contains four environmentally sealed, IP67, 20,000 lb single-ended, shear beam load cells
- Treaded top plate
- JB4SS TuffSeal® signal trim top access junction box
- Top access foot adjustment holes
- Carbon steel captured ball feet
- 20 ft SURVIVOR® EL147HE cable
- Non Legal for Trade
- Includes (2) 1-8 NC eye bolts
Load Ranger Wheel Pad Scale
Load Ranger Wheel Pad Scale
Load Ranger Wheel Pad Scale
- p to 6 individual pads (3 sets) per system, completely wireless
- 14 individual pads (7 sets) per system maximum, joined via cable, wireless communication to indicator
- Industrial Bluetooth® radio module for ability to communicate with indicator
- Integrated wheels and non-slip rubber under platform
- Built-in indicator on each scale with 1 in character display
- IP68 rating
RW-S & L
Load Ranger Wheel Pad Scale
RW-P Series
- RW-S - 10,000 x 5 lb/5,000 x 2 kg
- RW-L - 20,000 x 10 lb/10,000 x 5 kg
- Easy-to-carry Steel Handle
- Battery Operated with AC adapter/charger
- Charger Included
- Easy to Read 1"" LCD Display with Backlight
- Scales are linkable for multi-axle weighing
- Shock load protection
- Cast Aluminum Construction - Water Resistant
- Legal for Trade
RW-P Series
Load Ranger Wheel Pad Scale
RW-P Series
- 20,000 x 10 lb and 30,000 x 20 lb
- Lightweight and Low Profile (1.5"" High)
- Designed for Portability
- Solid Rubber Ramps
- By Wheel Weight or Total Weight
- Connect up to 6 scales with RW2601P
